Lowrance HDS Live Multi-Function DisplayWithActive Imaging SonarThe Lowrance HDS LIVE offers the best collection of innovative sonar features available, including Active Imaging, optional StructureScan 3D with Active Imaging, FishReveal and LiveSight sonar -- plus exciting functionality like C-MAP Genesis Live mapping and LiveCast smartphone integration.Year after year, more fishing tour pros use HDS than all other fishfinder brands combined. HDS LIVE carries on that tradition behind premium performance with the best collection of innovative sonar features available. You will experience a new level of fishfinding performance with HDS LIVE. Navigating to your favorite fishing spot or finding a new one has never been easier, behind the best suite of navigation features ever built into the HDS Live display -- including preloaded C-MAP US Enhanced mapping with 1-foot contours on 4,000-plus lakes, C-MAP Easy Routing, Navionics Autorouting and C-MAP Genesis Live mapping. HDS LIVE also simplifies your time on the water with onscreen text messages and call notifications, as well as LiveCast smartphone connection, which allows you to display video, Google Maps and fishing data on your fishfinder display.See structure and cover with a new level of refined detail and at a range unmatched by any other structure-imaging technology with Active Imaging 3-in-1 Sonar featuring CHIRP, SideScan and DownScan with FishReveal. The high-level clarity, target separation and detail of Active Imaging Sonar will help you find more fish by making it easier to quickly identify fish-holding structure like rockpiles, standing timber, weedbeds, ditches and drop-offs -- all at a greater distance from your boat. Get the best of CHIRP Sonar and DownScan Imaging on one screen with the exclusive FishReveal Smart Target view that helps you easily recognize fish from structure and cover on high-detailed DownScan Imaging images.
Antenna: Internal 10Hz GPS; external option
Dimensions: 11.2"W x 6.56"H x 3.05"D
Display: 9" diag. multi-tough color LCD w/ keypad control
Interface: Ethernet (2 ports); NMEA 2000; NMEA 0183; HDMI & analog video in; USB port, Bluetooth.
Mapping: Preloaded C-Map Enhaced US charts w/ Genesis Live & Auto-Routing.
Other Functions: Options: Sonic Hub, Sirius WX/Audio, AIS, engine/fuel montoring, WiFi connectivity
Radar: Available 3G, 4G broadband or Halo pulse compression radar
Resolution: 1280 x 720 pixels
Sounder: Built-in 500 Watt 50/83/200KHz conventinal, Lo-Mid-Hi CHIRP, and 455/800KHz StructureScan sonar
Waypoints/Routes: Not Specified
Features:
- Smartphone notifications, High-performance quad-core processor, FishReveal Smart Target View
- C-MAP Genesis Live onscreen mapping, Easy Routing, Navionics Autorouting capability
- Full high-definition HDS SolarMAX HD multi-touch screen with the widest range of viewing angles -- viewable even through polarized sunglasses
- Preloaded high-detail C-MAP US Enhanced charts with 1-foot contours on 4,000-plus lakes
- Dual-Channel CHIRP and Live Network Sonar, NMEA 2000 engine support
- Wireless and Bluetooth connectivity; Radar and SonicHub-2 audio server connectivity
- Quick Access Control Bar, Heat Map feature and Enhanced Surface Clarity
- SmartSteer control for Xi5 Trolling Motor and Outboard Pilot, Built-in CHIRP and Broadband Sounder
- Optional StructureScan 3D with Active Imaging enhancements, mapping upgrades include C-MAP, Navionics and more
- Limited 2 Year Warranty
In the box:
- HDS Live unit
- Mounting bracket
- Powercord
- Installation hardware
- Documentation
